V2 RB26 6 throttle drive by wire system
SKU DTRITB
Original price
$0
Original price
$2,026.41
-
Original price
$2,026.41
Original price
Current price
$2,026.41
$2,026.41
-
$2,026.41
Current price
$2,026.41
In 2018 Dahtone designed the first commercially available drive by wire system for the OEM RB26 6 throttle body inlet. After 4 years and a combined 100,000km of road and race use they decided that it was time to update the system.
The V2 system now uses a Bosch based billet aluminium throttle actuator that has built in throttle position sensors. There is no need for any extra sensors, brackets, wires or connectors, everything functions just like a Bosch single throttle body would.
TPS tracking is perfect and max current draw is under 4 Amps, which means there is no need for any external control boxes or half bridge modules. It will work on any ECU that can run a Bosch drive by wire throttle body.
The system works with any 6 throttle inlet manifold (OEM, Nismo, Plazmaman, Hypertune or even N/A with velocity stacks) without the need for any extra parts.
It also fits with the OEM oil cooler/filter block assembly.
Dahtone build cars first and foremost not just parts so we know what works and what doesn't in the real world. Buy from the innovators not the imitators.
Parts Included
- 1 x Bosch based billet aluminium drive by wire actuator
- 1 x New Genuine Nissan throttle linkage
- 1 x Throttle shaft joiner
- 1 x Throttle shaft joiner with integrated linkage arm
- 1 x Throttle actuator arm
- 1 x Throttle actuator plug and pin kit
- 1 x Throttle actuator bracket
- 2 x weld in bungs ( 1/8 npt and 1/4 npt)
- Stainless fasteners
- Install guide is downloadable at the link below. ( Updated 05/06/2022 )
https://drive.google.com/file/d/1bybn0e9KCGP83UAXhV-Q_ZI6SDBtzsZF/view?usp=sharing
Vehicle Model Compatibility
Engine Model Compatability
Shipping Policy
- We endeavour to ship all regular and stocked items on same day, next day or within 5 business days of your order being placed
- Custom orders may take longer than regular shipping times but will have information about shipping time on the listing
- We take extra care in packaging your orders to ensure you quality parts arrive safely
- PRP accepts no responsibility for damage or loss to items/products/services from courier or shipping companies once we have received receipt for the third-party service
- All Items purchased from PRP are to be installed by a qualified mechanic at a licensed workshop
- Modifying your vehicle is illegal in some states and territories, the customer acknowledges that it is their responsibility to abide by the law and take the appropriate measures to ensure that their vehicle is roadworthy
- PRP assumes no responsibility for any work carried out, modifications made or parts supplied with regards to road use, as all our products are intended for track use only
Warranty/Return Policy
- Warranty only covers item/product/service supplied
- Warranty is for a full refund or exchange provided you keep your receipt
- Warranty is void if you tamper with products or bring them back in a different state to which they were sold to you
- Warranty does NOT cover costs of shipping to and from in any circumstance
- We do not cover costs of shipping for warranty claims or exchanges
- Exchanges or refunds if you change your mind or parts don't suit your vehicle will be decided on a case by case basis, you are required to do your own research
- All Items/Products/Services purchased from Platinum Racing Products are to be installed by a qualified mechanic at a licensed workshop and ALL warranty claims are dependent on this
- Modifying your vehicle is illegal in some states and territories, the customer acknowledges that it is their responsibility to abide by the law and take the appropriate measures to ensure that their vehicle is roadworthy
- Platinum Racing Products assumes no responsibility for any work carried out, modifications made or parts supplied with regards to road use, as all our products are intended for track use only
